- 19 x 15W Osram Ostar™ quad-colour LEDs (RGBW)
- RGB backlight for dual colour effects
- Adjustable beam angle: 5°- 60°
- 5° - 31,140 Lux @ 2m (full on), 60° - 2,246 Lux @ 2m (full on)
- 4kHz refresh rate
- Motorised zoom
- DMX channels: 8/10/16 or 26 selectable
- Auto, sound active, manual control and master/slave modes
- Forward facing show mode
- Pan/tilt auto correction
- 360° continuous pan and tilt
- 16-Bit pan/tilt positioning
- 0 - 100% dimming and variable strobe
- 4 dimming curves: Linear, square law, inverse square law and S-curve
- Supplied with quick release omega clamps
- Jog wheel menu with 2” LCD display
- PowerCON input/output
- 5-Pin XLR input/output
- 3-Pin XLR input/output
- Fan cooled
Barcode ID |
E0717 |
Size (mm) |
410 x 320 x 195 |
Weight (Kg) |
9.1 |
Lamp |
19 x 15W |
Location
Meatrack, Stage - Assembly Hall
